Basic Building Parameters
The basic parameters that define a pre-engineered building are: Building width, Building length, Building height, Roof slope, End bay length, Interior bay length and
PRE-ENGINEERED BUILDING
Pre-engineered buildings are defined by the following geometrical parameters: Building width, Length, Eave height, Roof slope, Sidewall bay spacing, end wall bay spacing and main frame module space. Also design loads are the basic parameter.
Building Length and width are defined by the distance between steel lines. Extreme surface edges of girts and purlins are treated as steel line. Sum of side wall bay spaces will be equal to the building length.
Eave height is the distance from Finished floor level to inter section point of roof and sidewall steel line.
Roof Slope is defined as the ratio between vertical distance and horizontal distance of the roof surface. Standard roof slopes are 0.5:10 and 1.0:10
To describe the side wall bay spacing, main frame column spacing to be referred start from back end wall steel line to right end wall steel line. Same way back end wall and front end wall bay spacing to be given from left side wall steel line to right side wall steel line.
Primary Main frames:
Pre-engineered buildings offer complete freedom of design to accommodate customers need. EBS has particularly developed several types to offer optimized economical configuration for customers to choose from according to space, span, crane and architectural requirements.
Frame
When building width is less than 25m, clear span frame will provide un-interrupted clear work space in the building. When building width is more than 25m, it will not be an economical choice to the customer.
Airport Hangers
The width of the buildings may vary from 30m to 90m depending upon the number and type of aircraft. Hangers up to 60m clear span are economically built using pre-engineering building system; however, for span exceeding 60m, a structural truss-column system becomes more economical.
Multi span Frame
The introduction of interior columns allows for greater spans without internal gutters and rainwater pipes. This type of design optimizes bay spacing, building weight and therefore cost.
Single Slope buildings are offered with single or multi-span modular options. Straight or tapered columns are available.
Multi Gable Buildings are maintaining a low ridge height for very wide buildings.
Curved Roof gives special appearance to the building and modular width also can be increased.
Roof system
When Concrete wall exist to support main building, utilizing the support, roof system will be the cost effective solution and more work space to the client can be achieved. However, there will be a limitation on building span.
Car Canopies
These building enhancements are ideal for car parking, building expansions. The structure can be made of hot-rolled or built-up sections. Lean-to’s require a supporting structure to take the lean-to reaction.
Secondary end wall Frame:
Simple end wall frame with pin connected rafter and columns will reduce the building weight and on cost. However, if future expansion of the building is expected along sidewall, Rigid frame should be used @ ends. Standard endwall column spacing would be 6 mts. Endwall column and rafter can be made from hot-rolled, built-up or cold form cee section. Flush girt are standard feature for end wall.
Cold form structure:
Supporting members for wall and roof panels are girt and purlins. Cold form Zee section is used as purlin and girt. Standard height of Zee and Cee sections are 210mm. However EBS can supply any depth of Zee and Cee sections ranging from 125mm to 300mm. Cee sections are widely used as frame open members; jamb, header and sills. Also Cee section is used as end wall column and rafter. Main advantage on cold form members are
- 1. As raw material is pre-galvanized, no painting is required and self rust proofing.
- 2. There is no welding involved in the members and production is automated, hence accurate and faster supply of final product is assured.
- 3. Member weight is relatively less, so handling will be very much eased.
Roof and wall bracings system.
Rod and angle bracings are used as wall and roof bracing system. End wall framing system carries wind load and transfers them through strut purlin and then bracings to the ground. Standard brace rods are rod dia 12, 16, 20, 25 and 32mm.
Roof Layout with bracings
Single Skin Panels
The panels used in the construction of DASHPROJECTS Pre-Engineered Buildings are composed of the following:
Base metal of either Galvalume coated steel conforming to ASTM
Steel Joists
Open web steel joist (OWSJ) is a lightweight steel truss consisting, in the standard form, of parallel chords and a triangulated web system, proportioned to span between bearing
The engineering section employs a team of design and detailing engineers equipped with the latest and most advanced software for both disciplines. All works are closely monitored to ensure that it
Steel Fabrication
ASSENT is one of the leading steel fabrication company in Dubai. We deliver experienced and dependable steel manufacturing and fabrication solutions for
Steel Erection
With over a decade of experience and a team of industry experts, ASSENT is a trusted Steel Erection Company in Dubai, UAE. We aim to provide a complete,
ASSENT provides top-of-the-line structural steel fabrication services. ASSENT works with the best designers and engineers to ensure that all projects meet high standards of excellence and to provide
The components of a Pre-engineered building (PEB) are manufactured at our plant according to the carefully engineered design, drawn as per the client’s specific project requirements. This
Cladding
ASSENT is one of the largest manufacturers of cold-rolled steel frame structures in the Middle East. We offer a wide range of panels and profiles to suit the industrial and commercial needs
EBS is capable of designing all kind of high complex steel structures such as high rise buildings, airport terminal buildings and industrial structures for process, petroleum and power plant
EBS has a total site area of 140,000 sq/m including 45,000 sq/m of covered fabrication area and 70,000 sq/m of storage area with the capacity to produce in excess of 70,000t of fabricated steelwork
Since the formation of Emirates Building Systems in 1997, Emirates building Systems has developed an excellent reputation and strong presence as one of the regional’s premier steel fabricator
Industrial Structures and Buildings.
Its design capacity, its substantial resources, its considerable output, its commitment to service make EBS a choice supplier for large industrial and
Mezzanine
A mezzanine is an elevated floor for use as office or store area. The mezzanine framing is connected to main frame and intermediate columns for support. The mezzanine framing consists of
EBS offers profile to suit structural, architectural, thermal lighting and corrosive circumstances. Structural constraints are satisfied by the range of corrugation spacing, thickness and materials
EBS also offers steel deck for steel buildings or mezzanines to suit structural specifications. There are two profiles available in EBS production line; they are EBS50X225 and EBS75X300 with covering
EBS offers fabrication and supply of crane bridge girders for over head cranes. Most girders are from plate formed box section. EBS plant is well equipped with advance fabrication facilities for
On the Middle-East and Regional scale of the Construction Business, CSCEC ME L.L.C. has been a world class leaders and has executed in some of the complex projects of various specialised disciplines
General Contracting
In normal traditional engagement for project deliverables in the construction industry where the Owner engages the Designer and Contractor separately, CSCEC-ME
China State Construction Engineering Corporation Middle East (CSCME) Infrastructure Division has been operating in the region since 2006, in these 6 years the division has added significant strength
China State Construction Engineering Corporation Middle East (CSCME) Mechanical, Electrical and Plumbing (MEP) division has been operating in UAE since 2003 along with the core CSCME’s building
The PEB Steel Structure of a Pre-Engineered Steel Building generally accounts for over 80% of the weight of the Pre-Engineered Steel Building. This 80% is an average and may change plus or
The unit of measure of hot rolled structures (structural steel) is the metric ton (MT). Hot Rolled Steel Structures applications include Multi Storey low rise buildings, equipment
Building Accessories and special buyouts (SBO’s)include sliding doors, rollup doors, personnel doors, fiberglass insulation, sandtrap louvers, windows, ridges ventilators. Some are
Mabani erection team is comprises of highly qualified and well trained site engineers and safety officers. The team has completed more than 500 projects in the GCC, Meddle & Far
Blast & Paint
Mabani state of the art blasting, painting & material handling system produce the highest quality with most enduring coating finish. Mabani has the most advanced and
The basic parameters that define a pre-engineered building are: Building width, Building length, Building height, Roof slope, End bay length, Interior bay length and Design loads.
Width
Length
Zamil Steel pre-engineered buildings are custom-designed to meet your exact requirements. The most common Primary Framing systems are shown below. Practically any frame geometry is possible. Consult
Purlins, girts and eave struts are secondary structural members used to support the wall and roof panels. Purlins are used on the roof; girts are used on the walls and eave struts are used at the
Nearly 70% of all single storey non-residential construction now utilizes preengineered buildings. Applications range from small car parking sheds to 90 m (+), wide clear span aircraft hangars to
The panels used in the construction of Zamil Steel Pre-Engineered Buildings are composed of the following:
Base metal of either Galvalume coated steel conforming to ASTM A 792M Grade 345B or
Liner panels have one metal skin surface with polystyrene foam board adhered to it for better insulation. In the past 20 years, end-users, contractors and consultants have become increasingly aware
Eave gutters, downspouts, curved eaves, wall flashings and trims are produced from the same material (base metal, thickness, substrate coating, paint finish and color) as the wall panels of the
Drawings
Zamil Steel produces its own shop drawings for the fabrication of your steel joists, trusses, structural steel components, steel deck and girts. For project design, bid preparation or
Open web steel joist (OWSJ) is a lightweight steel truss consisting, in the standard form, of parallel chords and a triangulated web system, proportioned to span between bearing points.
The main use
Steel Decks
Steel deck is a cold formed corrugated steel sheet supported by steel joists or beams. It is used to support concrete or insulating membrane of a roof.
Zamil steel decks are
Combining Hambro steel joists with poured concrete, the system consists of hybrid concrete/steel T-beams running in one direction and an integrated continuous slab in the other (see drawing below).
